OH1 Petrochemical Process Pumps (VMH02Z Series)
The VMH02Z series pumps are single-stage overhung petrochemical process pumps featuring end suction, top discharge, radially split casing, foot-mounted support, and a spiral volute pressure chamber, classified as API 610 OH1 type.
Product Features
Stable and reliable structural design
Broad hydraulic coverage
Internationally advanced in design and performance
New generation of high-efficiency and energy-saving product
For media with high solid content: Semi-open impeller with wear-resistant plates to effectively reduce maintenance costs
For low NPSHa conditions: Inducer added at the impeller inlet to significantly improve cavitation resistance
For condensation- or crystallization-prone media: Multiple thermal insulation measures (steam, hot water, or electric) to ensure media fluidity
Product Introduction
Performance Range
- Flow Rate (Q)
- 4~2600 m³/h
- Head (H)
- 12~300 m
- Rotational Speed (n)
- 980, 1480, 2980 rpm
- Design Pressure (P)
- 2.5 MPa
- Operating Temperature (T)
- -40℃ to +150℃
- Standard
- API 610 12 th Edition Centrifugal Pumps for Petroleum, Petrochemical, and Natural Gas Industries
Applications
Petroleum Processing, Production, and Transportation
Coal Chemical Processes
Petrochemical and Chemical Processes
Natural Gas Industry
Metallurgy
Power
Boiler Circulating Water
Water Supply and Treatment
Offshore Industry
Seawater Desalination
Grain Deep Processing
