BB1 Horizontal Oil Transfer Pumps (VMB01 Series)
The VMB01 series pumps are horizontal, single-casing, side suction and discharge, foot-mounted or near-centerline-mounted, axially split, single-stage or two-stage petrochemical process pumps, classified as API 610 BB1 type.
Product Features
Independent R&D building upon international design concepts and manufacturing experience
Excellent hydraulics utilizing CFD and ANSYS software
Internationally advanced, representing a new generation of high-efficiency and energy-saving product
Advanced structure, stable operation, and high reliability
Multiple models on the range map, to ensure the rated point lies within the 80% to 110% range of the best efficiency point (BEP) for excellent efficiency
High strength baseplate enhances rigidity under heavy loads, ensuring system reliability
Product Introduction
Performance Range
- Flow Rate (Q)
- 100~12000 m³/h
- Head (H)
- 10~220 m
- Rotational Speed (n)
- 595, 740, 980, 1480, 2980 rpm
- Design Pressure (P)
- 2.5, 5.0, 11.0 MPa
- Operating Temperature (T)
- -20℃ to +160℃
- Standard
- API 610 12 th Edition Centrifugal Pumps for Petroleum, Petrochemical, and Natural Gas Industries
Applications
Petrochemical Processes
Coal Chemical Processes
Natural Gas Transportation
Crude/Finished Oil Pipeline Transportation
Marine Loading/Unloading Of Oil Tankers
Power
Offshore Industry
Water Supply and Treatment
General Industry
Aviation Kerosene Transportation at Airports
Pressure Boosting Systems for Power Plants, Thermal Plants, and Pipelines
