ANSI Standard Centrifugal Pumps (VMH01 Series)
The VMH01 series pumps are single-stage overhung petrochemical process pumps featuring end suction, top discharge, radially split casing, foot-mounted support, and a spiral volute pressure chamber.
Product Features
Stable and reliable structural design
Broad hydraulic coverage
Multiple configuration options
Multiple configuration options
Suitable for petrochemical industry and food deep processing Industry
New generation of high-efficiency and energy-saving product
Product Introduction
Performance Range
- Flow Rate (Q)
- Up to 1,500 m³/h
- Head (H)
- Up to 150 m
- Rotational Speed (n)
- 980, 1480, 2980 rpm
- Design Pressure (P)
- 2.5 MPa
- Operating Temperature (T)
- -40℃ to +150℃
- Standard
- ASME/ANSI B73.1-2020 Specification for Horizontal End Suction Centrifugal Pumps for Chemical Process
Applications
Coal Chemical industry
Refinery
Chemical Industry
Water Supply Systems
Waste Acid treatment
Sugar & Pharmaceutical Industries
Paper Industry
