Horizontal Axially Split Multistage Pumps (VMB03 Series)
The VMB03 series pumps are horizontal, side suction and discharge, multistage, near-centerline-mounted, axially split, between-bearing heavy-duty petrochemical process pumps, classified as API 610 BB3 type.
Product Features
Independent R&D building upon international design concepts and manufacturing experience
Excellent hydraulics utilizing CFD and ANSYS software
Internationally advanced, representing a new generation of high-efficiency and energy-saving product
Advanced structure, stable operation, and high reliability
Inlet/outlet nozzles located on the lower casing, allowing pump system assembly/disassembly without removing pipelines or motor
Double volute casing design with back-to-back impeller arrangement for self-balanced axial forces and extended bearing life
Impellers mounted to the shaft via shrink fitting for enhanced stability and reliability
Rolling, hydrodynamic or forced-lubrication bearings are available based on power and speed
Product Introduction
Performance Range
- Flow Rate (Q)
- 50~2000 m³/h
- Head (H)
- Up to 1500 m
- Rotational Speed (n)
- 980, 1480, 2980 rpm
- Design Pressure (P)
- 11.0, 15.0 MPa
- Operating Temperature (T)
- -80℃ to +180℃
- Standard
- API 610 12 th Edition Centrifugal Pumps for Petroleum, Petrochemical, and Natural Gas Industries
Applications
Petroleum Processing, Production, and Transportation
Coal Chemical Processes
Petrochemical and Chemical Processes
Seawater Desalination
Crude Oil Transportation
Water Supply
Oilfield Water Injection
Lean/Rich Liquid Pumps in Ammonia Synthesis Plants
Methanol Lean Pump Transportation
Boiler Feedwater
High-Pressure Hydraulic Energy Recovery Turbines
