TCM Series Liquid-ring Vacuum Pump
Compared with flat sided two-stage liquid ring pumps, it features high efficiency, energy saving, stability, reliability, and easy maintenance.
Product Features
Ultimate Vacuum
2.7kPa (A), high-efficiency range 3.3~20kPa (A)
Strong Adaptability
Capable of suctioning high-humidity gases (including saturated steam), gases containing solid particles, as well as toxic, corrosive, flammable, explosive, and hazardous gases
Mechanical Seal
Single or double mechanical seal options are available
Rich Material Options
Over 10 material options, including cast iron, stainless steel, or superalloys
Cavitation Prevention
Unique cavitation prevention design
Simple Structure
Two-stage compression with one impeller, featuring a simple structure
High Efficiency & Energy Saving
Large-diameter radial suction and discharge ports, with the conical portion extending into the impeller chamber, ensure smooth flow with minimal air and water resistance, achieving 10% energy savings
Anti-Over-Compression Design
Anti-over-compression design during startup enhances efficiency and shortens pre-evacuation time
Symmetrical Eccentricity of Two-Stage Impellers
Counteracts part of the radial force, leading to low vibration, minimal noise, and high stability
Side Discharge Design
Side discharge design with low starting current prevents equipment damage from overload during startup
Easy Maintenance
Fewer mechanical parts guarantee easy maintenance
Product Introduction
Performance Range
- Ultimate Vacuum
- 2.7kPa (A), high-efficiency range 3.3~20kPa (A)
- Capacity Range
- 420~4600 m³/h
Applications
Coal-Fired Power Plants
Gas-Fired Systems
Nuclear Power Plants
Waste-to-Energy Power Plants
Condenser Vacuuming
Fly Ash Desulfurization
Sugar Production
Distillation
Crystallization
Drying
Flash Evaporation
