2BE3 Series Liquid Ring Vacuum Pumps and Compressors
Low-speed, heavy-load design; with a cavitation protection device; stainless steel shaft sleeve enhances shaft service life. Internal inspection of the pump and replacement of the exhaust valve plate, shaft sleeve, and shaft seal can be performed through inspection ports without disassembly.
Product Features
Ultimate Vacuum
Vacuum pump ultimate vacuum 2.7kPa (A), high-efficiency range 3.3~20kPa (A)
Maximum Discharge Pressure
Compressor max. discharge pressure 0.15MPa (G), with isothermal compression
Strong Adaptability
Capable of suctioning high-humidity gases (including saturated steam), gases containing solid particles, as well as toxic, corrosive, flammable, explosive, and hazardous gases
Multi-Purpose Pump
By adding an intermediate partition, both ends can operate under different suction pressures, and the suction pressure difference can reach 33kPa
Cavitation Protection
Equipped with a cavitation protection device
Stable and Reliable
Low-speed and heavy-load, high reliability
Long Shaft Life
Stainless steel shaft sleeves extend the service life of the shaft
Flexible Installation
Reserve side suction and exhaust ports, and suction and exhaust can be set at the top or side respectively
Convenient Maintenance
No need for disassembly, the internal condition of the pump can be inspected through the inspection hole, and the exhaust valve plate, shaft sleeve and shaft seal can be replaced
Multiple Sealing Options
Packing seal, single mechanical seal, double mechanical seal, and dry gas seal options are available
Rich Material Options
Over 10 material options, including cast iron, stainless steel, or superalloys
Product Introduction
Performance Range
- Ultimate Vacuum
- 16 kPa (A)
- Vacuum Pump Capacity Range
- 2000~34000 m³/h
- Maximum Discharge Pressure
- 0.15 MPa (G)
- Compressor Capacity Range
- 3000~17500 m³/h
Applications
Pulp and Papermaking
Mine
Methane Gas
Sugar Production
Solvent Dewaxing
Tobacco
Belt Filters
Exhaust Gas Boosting
