SM/SME Series Liquid Ring Vacuum Pumps and Compressors
Different distributors can be selected according to operating conditions, such as high vacuum, high flow rate, and compressor types. Coaxial motor and pump design achieves 30% more compact size; light-load, high-speed operation delivers higher efficiency at the same flow rate. Single mechanical seal or “zero” leakage magnetic drive can be used.
Product Features
Ultimate Vacuum
Vacuum pump ultimate vacuum 3.3kPa (A)
Maximum Discharge Pressure
Compressor max. discharge pressure 130kPa (G), with isothermal compression
Strong Adaptability
Capable of suctioning high-humidity gases (including saturated steam), gases containing solid particles, as well as toxic, corrosive, flammable, explosive, and hazardous gases
Multiple Distributor Choices
Different distributors can be selected according to operating conditions: high vacuum, large water volume, compressor
Compact Structure
Coaxial motor and pump design achieves 30% more compact size
High Efficiency & Energy Saving
Light-load and high-speed, high efficiency under the same flow rate
Low-Consumption & Eco-Friendly
Minimized water consumption for better environmental sustainability
Low-Noise Operation
<75dB (A)
Cavitation Protection
Equipped with a cavitation protection device
Long Shaft Life
Stainless steel shaft sleeves extend the service life of the shaft
Robust Sealing
Single mechanical seal or "zero" leakage magnetic drive can be selected
Rich Material Options
Over 10 material options, including cast iron, stainless steel, or superalloys
Product Introduction
Performance Range
- Ultimate Vacuum
- 3.3 kPa (A)
- Vacuum Pump Capacity Range
- 10~241 m³/h
- Maximum Discharge Pressure
- 130 kPa (G)
- Compressor Capacity Range
- 20~200 m³/h
Applications
Vacuum Filtration
Vacuum Drying
Vacuum Crystallization
Vacuum Concentration
Vacuum Distillation
Vacuum Sterilization
Vacuum Priming
Laboratory Vacuum
Ventilation
Gas Aeration
Biogas
